Magnets above the conveyor / Overband magnetic separator – MSF
We ship within 24 hours
We ship goods within 24 hours on business days.
9,000,000 pcs IN STOCK
We have more than 9,000,000 items in stock.
23 years on the market
We are a Czech company with 23 years of experience on the market.
Thousands of satisfied customers.
Thousands of packages shipped and satisfied customers.
No product's description available
Additional parameters
| Category: | Overview of the range of magnetic separators |
|---|---|
| Cleaning method: | Automatic |
| Engine: | NORD SK9022.1AZBDH-100LP/4 TF |
| Gearbox type: | Worm gearbox |
| Installation: | Above the conveyor with max. width 800 mm (31 1 ⁄2 in) |
| Magnet type: | Ferrite |
| Magnetic circuit type: | Standard (single pole) |
| Magnetic plate dimension: | 800 x 660 mm |
| Machine operating temperature: | -20 ~ +40 °C (-4 ~ +104 °F) |
| Material of the separator strip: | Rubber EP 100 |
| Separated material: | Loose mixtures* |
| Separator belt speed: | 1,22 m/s (2,73 mph) |
| Suspension type: | 4x Eye bolt Ø 35 mm |
| Total weight: | 1275 kg |
| Wiring: | With no electrical installation (the motor ends with its control voltage terminal plate) |
